Nucleic Acid Purification System — Auto-Pure 10B

Auto-Pure 10B is a miniaturized magnetic bead method nucleic acid extraction and purification instrument, which is developed on the basis of Auto-Pure 20B and Auto-Pure 32A. Auto-Pure 10B can extract 10 samples in one run, maximum sample volume is 5 ml. With different types of magnetic bead nucleic acid reagents, it can quickly extract nucleic acids from animal and plant tissues, blood, body fluids, criminal specimens and other samples.

Inquiry More


•4.3 inch touch screen, easy to use

•Temperature and protocols can be edited and saved according to different reagent requirements

•Short operation time: 15~30 min per run

•High yield of nucleic acid with low magnetic bead loss and good repeatability of results

•UV sterilization, avoid cross contamination

•Open system which can apply to different magnetic bead extraction reagent

•APP software (Android system) which can monitor the system in real time through mobile device

•Using the PC software, user operate easily the machine

•Screw rod design which guarantee high operating accuracy; large guide rail design makes the structure more reliable

•With QR code identification function, special reagent can be recognized, no need to program or obtain protocols

•Open instrument parameter settings, can set freely: mixing speed, magnetic absorption, release, cooling fan and other functions

•Small volume, suitable for extraction on site

•The maximum sample processing volume is 5 ml, and it can process up to 10 samples in one run. The instrument has lysis hole and elution hole heating function
