Nucleic Acid Purification System — Leap-Pure R16

Leap-Pure R16 uses the same extraction block as  Leap-Pure S24, with a sample throughput of 1~16, and  supports the extraction of general samples, FFPE block and  cfDNA. At the same time, a set of pipetting parts is built in,  which is suitable for the set-up of QPCR and digital PCR,  and supports the general 96-well PCR plate and various  digital PCR chips, which can be freely selected according to  the actual situation.

Inquiry More

Leap-Pure R16.jpg

Model

Leap-Pure R16
Function

Automatic pipetting and nucleic acid extraction
Extraction principle

Extraction method combined with magnetic rods and magnetic combs based on magnetic bead method and pipetting type
Throughput

1~16
Sample

FFPE, whole blood, plasma, stool, sputum, etc
Pre-packaged reagent

Support the pre-packaged reagent to be directly on the machine and automatically prick the film
Information management

Support external code scanner
Visual recognition

Optional visual block can automatically identify the quantity and specification of consumables
Sample processing system

1~15 mL
Minimum elution volume

20 μL
Stability

CV ≤5 %
Software operation

10-inch color touch screen, windows system software
Account management

User authorization management, programs and instruments can be customized
Instrument port

USB port, LAN port
Pollution control

Built-in HPEA, UV sterilization
Power supply

AC220 V, 50 Hz, rated power 450 W
Extraction Temp. control-purpose

Used for incubation in the extraction process, such as lysis, elution, etc
Extraction Temp. control-Temp. control range

RT. ~120 °C
Extraction Temp. control-Temp. accuracy

≤±1 °C at 100 °C
Extraction Temp. control-Temp. uniformity

≤3 °C at 100 °C
Extraction Temp. control-Temp. stability

≤±0.5 °C at 100 °C
Reagent refrigeration-purpose

Used for reagent refrigeration and supports automatic refrigeration at startup
Reagent refrigeration-Temp. control range

4 °C~95 °C
Reagent refrigeration-Temp. accuracy

≤±1 °C at 4 °C
Reagent refrigeration-Temp. uniformity

≤1 °C at 4 °C
Pipetting block 1-purpose

Nucleic acid extraction
Pipetting block 1-pipetting range

20~1000 μL
Pipetting block 1-precision

20 μL≤2.5 % 100 μL≤1.25 % 500 μL≤0.4 % 1000 μL≤0.4 %
Pipetting block 1-accuracy

20 μL≤±5 % 100 μL≤±2 % 500 μL≤±1 % 1000 μL≤±1 %
Pipetting block 2-purpose

Automatic pipetting
Pipetting block 2-pipetting range

1~200 μL
Pipetting block 2-precision

1 μL≤5 % 20 μL≤2 % 100 μL≤1 % 200 μL≤1 %
Pipetting block 2-accuracy

1 μL≤±12 % 20 μL≤±2 % 100 μL≤±1 % 200 μL≤±1 %
