Product|Hangzhou Allsheng Instruments

•Dual channel fluorescence excitation detection

•More reliable results

Side light detection system which makes minimum detection of 20 ul reaction volume possible

Accurate temperature control, temperature difference between wells less than 0.15 ℃, the temperature control accuracy can reach to 0.1 ℃

Real-time monitoring of fluorescence signal which avoiding subjective error caused by manual interpretation

•Easy operation

The negative and positive results are directly interpreted without any other calculations

With 7 inch touchscreen, stand-alone operations like settings, detection, interpretation and save are available, no need connecting computer

User-friendly software with two-channel fluorescence detection to match with different requirements of kits

•Provides multiple data export methods

Use USB, WIFI connection, transfer the experimental data and results to your computer, or save the data directly to the cloud through WIFI (need to be developed according to customer needs)

•View results on your computer, organize and share data

Once the data is exported, you can use the PC software to view the data in various formats and organize the experimental data

•Easy-to-use "data printer" option

You can print results directly from the instrument via the USB printer interface. You can also use PC software to print and export the results from the computer

•Convenient for outdoors portability

Small size with rechargeable batteries makes detection real-time anywhere

Portable test box which is easy equip with other instruments to improve the efficiency of the experiment

•Software systems are smarter

The software on the instrument side is simple and clear, and beginners can easily master it

Android mobile APP software can control the operation of monitoring instruments

It can be operated by an external computer to meet various customer needs

Mobile APP real-time data transmission, real-time monitoring system

Data statistics function to record experimental parameters and data, which is convenient for traceability and search

Real-time monitoring, automatic identification of negative and positive, melting curve and other functions

Model

Gene-8C2
Light source

Blue·LED Green·LED
Excitation wavelength

Ex 470 nm / LED Ex 525 nm / LED
Detection wavelength

Em 535 nm / PD Em 605 nm / PD
Detector

S1337-66BQ · Detection capability 190-1100nm
Sample tube type

0.2 flat single tube & 8-strip tube
Temperature range

10~99℃ (thermo lid: RT.~110℃)
Max heating speed (℃)

≥2℃/s
Max coolinig speed (℃)

≥2℃/s
Temp. uniformity (℃)

39℃:0.3℃; 63℃:0.6℃; 95℃:1.0℃
Temp. control accuracy (℃)

±0.2℃
Temp. control precision (℃)

≤0.1℃
Thermo lid heating rate

30℃-105℃ ·t<125s
Fluorescence repeatability

CV≤3%
Fluorescence precision

CV≤5%
Detection limit

≥10%
Peak consistency

≤10%
Input power

15V 6.67A
External interface

USB(Type ·A)×2.USB(Type ·B)×1
Display screen

7-inch touch screen
Instrument size (DxWxH)

305mm×148mm×104mm

Code

Description
AS-20010-00

Gene-8C isothermal fluorescence PCR
AS-20020-00

Gene-8C2 isothermal fluorescence PCR
Fluorescence quantitative PCR reagents
RS-QP01001

qPCR probe master mix (probe method)
RS-QP01002

U+qPCR probe master mix (probe method)
RS-QP01003

WSSV fluorescence quantitative PCR kit (probe method)
RS-QP01004

IHHNV fluorescence quantitative PCR kit (probe method)
RS-QP01005

EHP fluorescence quantitative PCR kit (probe method)
RS-QP01006

One step qRT-PCR probe master mix (probe method)
RS-QP01007

U+One step qRT-PCR probe master mix (probe method)
RS-QP01008

TSV fluorescence quantitative PCR kit (probe method)
Isothermal amplification PCR reagents
RS-IP01001

Isothermal amplification PCR master mix
RS-IP01002

Isothermal amplification PCR master mix (RNA template)
Aquatic virus series
RS-IP02001

WSSV isothermal amplification PCR master mix kit
RS-IP02002

IHHNV isothermal amplification PCR master mix kit
RS-IP02003

EHP isothermal amplification PCR master mix kit
RS-IP02004

TSV isothermal amplification PCR master mix kit
RS-IP02005

SHIV isothermal amplification PCR master mix kit
Animal source doping series
RS-IP03001

Porcine gene isothermal amplification PCR kit
RS-IP03002

Chicken gene isothermal amplification PCR master mix kit
RS-IP03003

Duck gene isothermal amplification PCR master mix kit
RS-IP03004

Bovine gene isothermal amplification PCR master mix kit
RS-IP03005

Sheep gene isothermal amplification PCR master mix kit
Cell-free recombinant protein expression kit
RS-IP04001

Non-dialysis Escherichia coli cell-free recombinant protein expression kit
RS-IP04002

Analytical Escherichia coli cell-free recombinant protein expression kit
RS-IP04003

High-throughput dialysis-type Escherichia coli cell-free recombinant protein expression kit
